Temperature range |
-25...150 °C |
-25...150 °C |
-40...200 °C |
-40...200 °C |
-45...200 °C |
-45...200 °C |
Temperature stability |
±0.02 °C |
±0.02 °C |
±0.05 °C |
±0.02 °C |
±0.02 °C |
±0.02 °C |
Temperature Control |
TAC, self-optimizing (True Adaptive Control) |
TAC, self-optimizing (True Adaptive Control) |
TAC, self-optimizing (True Adaptive Control) |
TAC, self-optimizing (True Adaptive Control) |
TAC, self-optimizing (True Adaptive Control) |
TAC, self-optimizing (True Adaptive Control) |
Controller |
Pilot ONE (E-grade "Basic") |
Pilot ONE (E-grade "Basic") |
Pilot ONE (E-grade "Basic") |
Pilot ONE (E-grade "Basic") |
Pilot ONE (E-grade "Basic") |
Pilot ONE (E-grade "Basic") |
Safety class |
III / FL |
III / FL |
III / FL |
III / FL |
III / FL |
III / FL |
Protection class |
IP20 |
IP20 |
IP20 |
IP20 |
IP20 |
IP20 |
Dimensions (W x D x H) |
8.86 x 14.57 x 16.89 in |
8.86 x 14.57 x 16.89 in |
10.04 x 17.72 x 18.74 in |
10.04 x 17.72 x 18.74 in |
11.81 x 18.31 x 20.31 inches |
11.81 x 18.31 x 20.31 inches |
Weight |
55.12 pounds |
55.12 pounds |
81.59 pounds |
86 pounds |
97.02 pounds |
97.02 pounds |
Heating / Cooling Capacity |
Heating capacity |
1 kW |
1 kW |
1,6 - 2,1 kW |
1,5 kW |
1,6 kW |
1,6 kW |
Cooling capacity |
100 20 0 -10 -20 °C 0,3 0,3 0,21 0,15 0,05 kW |
100 20 0 -10 -20 °C 0.3 0,3 0,2 0,15 0,1 kW |
100 20 0 -10 -20 -40 °C 0,42 0,42 0,38 0,33 0,25 0,05 kW |
100 20 0 -10 -20 -40 °C 0,42 0,42 0,38 0,33 0,25 0,05 kW |
100 20 0 -10 -20 -40 °C 0,6 0,6 0,55 0,42 0,35 0,05 kW |
100 20 0 -10 -20 -40 °C 0,6 0,6 0,55 0,42 0,35 0,05 kW |
Cooling machine |
air-cooled |
water-cooled |
air-cooled |
water-cooled |
air-cooled |
water-cooled |
Refrigerant |
R290 (A3, H220) (0,066 kg) |
R290 (A3, H220) (0,06 kg) |
R290 (A3, H220) (0,099 kg) |
R290 (A3, H220) (0,06 kg) |
R290 (A3, H220) (0,099 kg) |
R290 (0,06 kg) |
Circulation Pump |
Pressure pump max. |
22 lpm ; 0.7 bar 5.81 gpm ; 101.5 psi |
22 lpm ; 0.7 bar 5.81 gpm ; 101.5 psi |
22 lpm ; 0.7 bar | 5.81 gpm ; 10.15 psi |
22 lpm ; 0.7 bar | 5.81 gpm ; 10.15 psi |
22 lpm ; 0.7 bar | 5.81 gpm ; 10.15 psi
|
22 lpm ; 0.7 bar 5.81 gpm ; 101.5 psi |
Suction pump max. |
16 lpm ; 0.4 bar 4.23 gpm ; 58 psi |
16 lpm ; 0.4 bar 4.23 gpm ; 58 psi |
16 lpm ; 0.4 bar 4.23 gpm ; 58 psi |
16 lpm ; 0.4 bar | 4.23 gpm ; 5.8 psi
|
16 lpm ; 0.4 bar | 4.23 gpm ; 5.8 psi
|
16 lpm ; 0.4 bar 4.23 gpm ; 58 psi |
Pump connection |
M16x1 AG male |
M16x1 AG male |
M16x1 AG male |
M16x1 AG male |
M16x1 AG male |
M16x1 AG male |
Permissible viscosity |
50 mm²/s |
50 mm²/s |
50 mm²/s |
50 mm²/s |
50 mm²/s |
50 mm²/s |
Connections |
Digital interface |
Pt100 |
Pt100 |
Pt100 |
Pt100 |
Pt100 |
Pt100 |
Digital interface |
RS232, Ethernet, USB Device, USB Host |
RS232, Ethernet, USB Device, USB Host |
RS232, Ethernet, USB Device, USB Host |
RS232, Ethernet, USB Device, USB Host |
RS232, Ethernet, USB Device, USB Host |
RS232, Ethernet, USB Device, USB Host |
Operating Data |
Permissible ambient temp. |
5...35 °C |
5...40 °C |
5 to 40 °C |
5 to 40 °C |
5 to 40 °C |
5 to 40 °C |
Noise level |
- |
- |
59 dB(A) |
- |
- |
|
Bath opening W x D / BD |
178 x 80 / 120 mm | 7.01 x 3.15 / 4.72 inches |
178 x 80 / 120 mm | 7.01 x 3.15 / 4.72 inches |
170 x 85 / 135 mm | 6.69 x 3.35 / 5.31 inches |
170 x 85 / 135 mm | 6.69 x 3.35 / 5.31 inches |
205 x 85 / 157 mm | 8.07 x 3.35 / 6.18 inches |
205 x 85 / 157 mm | 8.07 x 3.35 / 6.18 inches |
Bath volume |
2.75 Liters | 0.73 gal |
2.75 Liters | 0.73 gal |
3.2 Liters | 0.85 gal |
3.2 Liters | 0.85 gal |
4.9 Liters | 1.29 gal |
4.9 Liters | 1.29 gal |
Filling volume min |
2 Liters | 0.53 gal |
2 Liters | 0.53 gal |
2.8 Liters | 0.74 gal |
2.8 Liters | 0.74 gal |
4.5 Liters | 1.19 gal |
4.5 Liters | 1.19 gal |
Cooling water connection |
- |
G1/2 AG |
- |
G1/2 AG |
- |
G1/2 AG |
Cooling water differential pressure min. |
- |
2 bar | 29 psi |
- |
2 bar | 29 psi |
- |
2 bar | 29 psi |
Cooling water pressure max. |
- |
6 bar | 87 psi |
- |
6 bar | 87 psi |
- |
6 bar | 87 psi |
Power supply |
110-120V 1~ 60Hz |
110-120V 1~ 60Hz |
208-240V 1~/2~ 50/60Hz |
110-120V 1~ 60Hz |
208V 2~ 60Hz |
208V 2~ 60Hz |
Current max. |
11,5 A |
11,5 A |
14 A |
14 A |
10,5 A |
- |
Fusing |
16 A |
16 A |
16 A |
16 A |
2x16 A |
- |
