HUBER CC-505 Refrigerator Bath Circulator


HUBER CC-505 Refrigerator Bath Circulator

(Please Note: There is up to 3 weeks Shipping lead time)

 This Refrigeration Bath Circulator controls the temperature of externally connected applications and Thermoregulation of objects directly in the thermostat bath. Typical applications are: photometers, refractometers, viscometers, double-jacketed reaction vessels and autoclaves. The units can be used in laboratories, for determining the freezing point, for deep temperature calibration, for petroleum tests, for temperature control of measuring devices and experimental setups as well as for materials testing and quality control.


General Information & Temperature Controller
Temperature range -55 to 200 °C
Temperature stability ±0.02 °C
Temperature control TAC, self-optimizing (True Adaptive Control)
Controller Pilot ONE (E-grade "Basic")
Safety class III / FL
Protection class IP20
Dimensions (W x D x H) 16.14 x 18.9 x 30.08 inches
Weight 136.71 Lb
Heating / Cooling Capacity
Heating capacity 1,6 kW
Cooling machine air-cooled
Refrigerant R507 (13.22 Lb)
Circulation Pump
Pressure pump max. 6.6 gpm ; 10.15 psi
Suction pump max. 4.89 gpm ; 5.8 psi
Pump connection M16x1 AG male
Permissible viscosity 50 mm²/s
Pt100 connection Pt100
Digital interface RS232, Ethernet, USB Device, USB Host
Operating Data
Old sku 2018.0010.01
Permissible ambient temp. 5 to 40 °C
Bath opening WxD/BD 4.72 x 4.33 / 5.91 inches
Bath volume 5 Liters / 1.32 gal
Filling volume min. 4 Liters / 1.06 gal
Power supply 208V 2~ 60Hz
Current max. 12,5 A
Fusing 2x16 A

HUBER CC-505 Refrigerator Bath Circulator

Product form

SKU: 2044.0003.01
