Cold Traps

NEOCISION Cold Trap with Pump - ETL Rated - (-40c) Looking for a cold trap and small application chiller? The BVV™ CT40 features a 2-in-1 use with a cold trap function and built in circulating system for small batch temperature control.  Cold Trap Function Use the BVV™ CT40 to condense vapors down to -40°C before they reach your vacuum pump. This prolongs the life of the vacuum system, reduces the need to change oil frequently, and efficiently traps vapors otherwise lost to evaporation such as terpenes. Common applications include short path distillation, rotary evaporation, reactor setups, or any other application where volatile vapors can damage your vacuum pump. Chiller Function Use the BVV™ CT40 for small batch temperature control down to -40°C. Switch out the cold trap configuration with solid lid to turn your cold trap into a chiller. Common applications include condensing coils, small vessel setups, heat exchangers. Operating 2-in-1 Simultaneously Use the BVV™ CT40 as a cold trap and chiller. The unit can be used with the cold trap configuration and circulating function simultaneously. Commonly used as for chilling applications with no additional heat load.     BVV™-CTC40-WP Power Requirement AC 110V +/- 10% / 60Hz Relative Humidity < 85% Cooling Capacity 400W Refrigerant R404A Cold Trap Capacity 3 x 300ml Cold Trap Barb Dia. 10mm Reservoir Capacity 6.8L External Dimensions 305 x 485 x 635mm Weight 149 lbs     Call in to see how we can pair this unit with your setup Please Note: This device is designed for operation on its own independent circuit breaker. For best results, do not use this device on a breaker shared with other equipment. ***Notice to Customers: All units are inspected for broken glass or parts before the unit is shipped. If unit arrives damaged or glass is broken (this does not include minor imperfections or scuffs in glassware), Customer MUST contact BVV™ within 3 days of delivery to file a claim and receive a replacement part. If customer DOES NOT contact BVV™ within 3 days of delivery responsibility for replacement parts falls on the customer and they must pay for replacement pieces.*** ***Glassware Safety Disclaimer: BVV™ is not responsible for failure of glassware which must be inspected before and after every use because it may eventually develop imperfections or damage through normal usage, mishandling, and stress caused by temperature variations. If an imperfection or damage is noted while inspecting the glassware DO NOT use the glassware because it can fail causing bodily harm or damage to the surrounding area.***

Read more less

NEOCISION Cold Trap - ETL Rated - (-80c) The BVV™ CT80 Cold Trap is used to condense vapors lost in vacuum applications before they reach the vacuum system. This prolongs the life of the vacuum system, reduces the need to change oil frequently, and efficiently traps vapors otherwise lost to evaporation such as terpenes. The CT80 model reaches a maximum temp of -80°c or -112F under vacuum and contains three traps for maximum efficiency and condensation of vapors. Place in-line between application and your vacuum system. Specifications: Temp Range: -112F to Ambient Internal Dimensions: 180mm Internal Diameter x 210mm Depth (Holds about 1.4 gallons) External Dimensions: 505 x 620 x 750mm Weight: 149lbs Stainless Steel Interior 3x Pyrex Glass Traps 110V Power Please Note: This device is designed for operation on its own independent circuit breaker. For best results, do not use this device on a breaker shared with other equipment.   ***Notice to Customers: All units are inspected for broken glass or parts before the unit is shipped. If unit arrives damaged or glass is broken (this does not include minor imperfections or scuffs in glassware), Customer MUST contact BVV™ within 3 days of delivery to file a claim and receive a replacement part. If customer DOES NOT contact BVV™ within 3 days of delivery responsibility for replacement parts falls on the customer and they must pay for replacement pieces.*** ***Glassware Safety Disclaimer: BVV™ is not responsible for failure of glassware which must be inspected before and after every use because it may eventually develop imperfections or damage through normal usage, mishandling, and stress caused by temperature variations. If an imperfection or damage is noted while inspecting the glassware DO NOT use the glassware because it can fail causing bodily harm or damage to the surrounding area.***

Read more less

10” X 10” KF25 Cold Trap Kit Cold traps are used in vacuum applications where contaminating vapors may be present, and a cold trap is required to assure vapors are condensed before reaching the vacuum pump. They can be used with any pump but are mostly used with rotary vane pumps. Protecting your pump will greatly increase the life of all your seals and internal components it will also assure that a full vacuum is pulled based on the pump’s capabilities. BVV’s 10”X10” KF25 Cold Trap features 2 qty. KF25 ports. The lower port is connected to the system that is under vacuum and the top to the vacuum pump. The KF25 allows for a larger bore and works great for high flow applications. This kit comes with 2 qty. KF25 rings and 2 qty. KF25 clamps ready to be connected in line with your setup. The internal pot is stainless steel and can hold 1.5 gallons which will hold the dry ice slurry or other method of getting cold. A silicone O-ring sits around the 1.5-gallon pot and creates a seal with the top of the 10”X10” base. For more specifications, please view table and diagrams below. Product Information Sheet  **This cold trap comes pre-tested to pull down to 30 microns** **This cold trap is rated for applications down to 30 microns. If your application requires a deeper vacuum, please DO NOT USE THIS COLD TRAP** Specifications    Model       CTRAP10X10-B       Material of Base and Internal Pot       Stainless Steel       Gasket Material       Silicone       Lid Material       Silicone + Glass    Vacuum Rating       30 microns       Weight       29lbs       Overall Height       11.5”       Overall Diameter (Including Ports)       14”       Cold Trap Surface Area       234.45 sq.in       Internal Pot Volume       1.5 gallons    Chemical Compatibility with Glass Lid    Ethanol       Excellent         Acetone       Good    Water       Excellent       Propylene Glycol       Excellent       Isopropyl Alcohol       Excellent    Chemical Compatibility with Silicone O-Ring and Lid Seal    Ethanol       Good       Acetone       Good       Pentane       Good       Hexane       Good       Heptane       Good      View of 10” x 10” Cold Trap

Read more less

Cold Trap 2" Stainless Steel This Stainless Steel Cold is designed and intended for use with the Polyscience IP60 Cold Finger (Can also be used with dry Ice) to create a cold trap that can achieve extremely frigid temperatures. These cold traps have 2 1/4" FNPT ports with one having a dip tube to the bottom of the trap to achieve higher vapor condensing rates with the 2" Diameter Center opening for the IP60. This Cold trap also has an insulating vacuum jacket around the entire container to maintain the subzero temperatures and help achieve the maximum minimal temperature of the IP60. Unlike many cold Traps on the market, this one is also made out of 304 Stainless steel and the internal parts are resistant to most chemicals and easily cleaned due to the Tri-Clamp lid design. Specifications Material 304 Stainless Steel Temperature Rating -200 to 200°C Ultimate Vacuum <100millitorr / microns Cold Finger Internal Dimensions 1.85" x 11.75" (Fits Polyscience IP60) Trap Internal Dimensions 5.85" x 10" Outside Dimensions 8" x 14" x 15" (Includes jacket gauge and valve hardware) Weight 28LBS

Read more less

1.5 Gallon Cold Trap (2QT Tank) Dry Ice, Liquid Nitrogen - W/GLASS LID    This is a complete Cold Trap and will come assembled for instant use. This Cold Trap is made of 304SS MADE IN USA, utilizing Glass lids for Durability, flexibility and Chemical Resistance to alcohol and solvents.   This system is Recommended to protect pump from condensable vapors.   This Trap comes with an industrial grade, heat cured silicone gasket designed only for our systems. There is nothing of equal quality in the market. The gasket itself is reversible (doubling the life of our system guaranteed) allowing customers to instantly take it off and flip it over. No adhesives are used! The system will maintain a vacuum seal only under vacuum. The vacuum pump will hold the interior 2 quart container for your Dry Ice Slurry in compression with the larger outer lid. The larger outer Lid will be held in compression with 1.5 gallon outer container.   The connections on both sides are 1/4" MJIC flares or 1/4" Barbs that will connect to 1/4" HVAC or FJIC stainless steel hose.    The Center Slurry Container has a lid for it, This lid simply helps prevent evaporation of your slurry.   Temperature rated for -100-160F   This Cold Trap comes assembled and includes:  (1) 1.5gl high strength Stainless steel outer container (made of solid 304 stainless made in USA) (1) 2q interior Slurry Container (made of solid 304 stainless made in USA) (2) 1/2" thick clear Glass lids (2) Industrial grade silicone gasket (1) 1/4" HVAC Hose 5' Can withstand max working temps of 392F gasket only 60A durometer density (1) Max vacuum -29.5inHg (+/-.5Hg) (2) 1/4" MJIC or Barb Fittings    Outside Container Internal Dimensions: 7.25" Diameter X 8.25" Tall    To help remove condensable vapors, or when liquid nitrogen traps are not practical, our Cold Trap is the best option for preventing vapors from getting into your vacuum pump and contaminating it. This 1.5 gallon trap uses Glass lids for durability, flexibility, and chemical resistance. The system doesn’t use adhesives, and comes standard with a reversible gasket for enhanced quality that doubles its life.   Made in the USA, the BVV™ Cold Trap comes with all parts pre-assembled, so you can get to work straight out of the box.   Inside Container Internal Dimension: 4.75 Diameter by 6.5 Tall

Read more less

1.5 Gallon Cold Trap (2QT Tank) Dry Ice, Liquid Nitrogen (Comes with 2 Year Limited warranty)   This is a complete cold trap and will come assembled for instant use. This cold trap is made of 304SS MADE IN USA, utilizing Polycarbonate lids for durability, flexibility and chemical resistance to Ethanol and Isopropyl (not compatible with Acetone).   This system is recommended to protect pump from condensable vapors.   This trap comes with an industrial grade, heat cured silicone gasket designed only for our systems. There is nothing of equal quality in the market. The gasket itself is reversible (doubling the life of our system guaranteed) allowing customers to instantly take it off and flip it over. No adhesives are used! The system will maintain a vacuum seal only under vacuum. The vacuum pump will hold the interior 2 quart container for your dry ice slurry in compression with the larger outer lid. The larger outer lid will be held in compression with 1.5 gallon outer container.   The connections on both sides are 1/4" MJIC flares or 1/4" Barbs that will connect to 1/4" HVAC or FJIC stainless steel hose.    The center slurry container has a lid - this lid simply helps prevent evaporation of your slurry.   Temperature rated for -100-160F   This cold trap comes assembled and includes:  (1) 1.5gl high strength stainless steel outer container (made of solid 304 stainless made in USA) (1) 2q interior slurry container (made of solid 304 stainless made in USA) (2) 1/2" thick clear polycarbonate lids (2) industrial grade silicone gasket (1) 1/4" HVAC hose 5' Can withstand max working temps of 392F gasket only 60A durometer density (1) max vacuum -29.5inHg (+/-.5Hg) (2) 1/4" MJIC or Barb Fittings    Outside container internal dimensions: 7.25" diameter X 8.25" tall    To help remove condensable vapors, or when liquid nitrogen traps are not practical, our cold trap is the best option for preventing vapors from getting into your vacuum pump and contaminating it. This 1.5 gallon trap uses polycarbonate lids for durability, flexibility, and chemical resistance. The system doesn’t use adhesives, and comes standard with a reversible gasket for enhanced quality that doubles its life.   Made in the USA, the BVV™ Cold Trap comes with all parts pre-assembled, so you can get to work straight out of the box.   Inside container internal dimension: 4.75" diameter by 6.5" tall

Read more less

BVV™ Dewar Glass Cold Trap This dewar style glass is designed for maximum vapor condensation and it also has a 24/40 bottom joint and (2) GL-14 8mm Hose Barbs *Notice to customers: All units are inspected for broken glassware or parts before leaving BVV™. If the unit arrives damaged (this does not include minor imperfections or scuffs in glassware), the customer MUST contact BVV™ within 72 hours from carrier delivery to file a claim. If the customer DOES NOT contact BVV™ within 72 hours from carrier delivery, then BVV™ cannot issue any replacement(s) or compensation for the item; a new purchase will need to be made for a replacement.

Read more less

Replacement Trap for CT40 and CT80 Cold Traps This is a replacement glass trap for the SH Scientific CT40 and CT80 model cold traps. The trap fits in the lid of the cold traps and is suspended in the chilling fluid. Specifications: 3/8" Hose Barb Connection 34/45 Joint 2" Diameter x 10" Height Material: Boro 3.3 *Notice to customers: All units are inspected for broken glassware or parts before leaving BVV™. If the unit arrives damaged (this does not include minor imperfections or scuffs in glassware), the customer MUST contact BVV™ within 72 hours from carrier delivery to file a claim. If the customer DOES NOT contact BVV™ within 72 hours from carrier delivery, then BVV™ cannot issue any replacement(s) or compensation for the item; a new purchase will need to be made for a replacement.  **Glassware Safety Disclaimer: BVV™ is not responsible for failure of glassware which must be inspected before and after every use because it may eventually develop imperfections or damage through normal usage, mishandling, and stress caused by temperature variations. If an imperfection or damage is noted while inspecting the glassware DO NOT use the glassware because it can fail causing bodily harm or damage to the surrounding area.**

Read more less

BVV™ Glass Cold Trap - Ribbed This dewar style glass is designed to increase surface area for maximum vapor condensation and it also has 24/40 or 34/45 jointed connections to increase vapor flow. Note: The bottom joint will always be 24/40. *Notice to customers: All units are inspected for broken glassware or parts before leaving BVV™. If the unit arrives damaged (this does not include minor imperfections or scuffs in glassware), the customer MUST contact BVV™ within 72 hours from carrier delivery to file a claim. If the customer DOES NOT contact BVV™ within 72 hours from carrier delivery, then BVV™ cannot issue any replacement(s) or compensation for the item; a new purchase will need to be made for a replacement.

Read more less

Dewar Style Glass Cold Trap The Dewar Style Glass Cold Trap with GL-14 Barb Fittings allows the user to load dry ice into the inner portion of the cold trap from the top to allow maximum condensation temperatures. This protects your vacuum pump and captures any vapors that were lost during evaporation or distillation. Made in the USA. Dewar Style Glass Cold Traps includes the following: Metal Keck Clip Boss Head Lab Stand Chain Clamp 250ml Round Bottom Flask 24/40 Joint 250-500ml Cork Stand Specifications: USA Made 24/40 Male Ground Joint GL-14 8mm Barb Connections OD = 3.8" ID = 2.75" Height = 14.75" *Notice to customers: All units are inspected for broken glassware or parts before leaving BVV™. If the unit arrives damaged (this does not include minor imperfections or scuffs in glassware), the customer MUST contact BVV™ within 72 hours from carrier delivery to file a claim. If the customer DOES NOT contact BVV™ within 72 hours from carrier delivery, then BVV™ cannot issue any replacement(s) or compensation for the item; a new purchase will need to be made for a replacement. **Glassware Safety Disclaimer: BVV™ is not responsible for failure of glassware which must be inspected before and after every use because it may eventually develop imperfections or damage through normal usage, mishandling, and stress caused by temperature variations. If an imperfection or damage is noted while inspecting the glassware DO NOT use the glassware because it can fail causing bodily harm or damage to the surrounding area.**

Read more less

Dry Ice Maker Machine Food Grade - Ultra Dense Block   This dry ice machine makes ice the way you want it! Using 2 tons of hydraulic force to compress the formed CO2 snow into a solid brick.  Other dry ice makers produce a loosely packed brick that sublimates quickly.  Our bricks take up to 1.5+ hours to sublimate.  All of the parts that touch liquid CO2 or ice are food-grade materials. Must use a CO2 tank with a dip tube!! Otherwise you will not get the liquid CO2 needed to make dry ice. Use Specifications 20lbs of CO2 Retail ($1/lb) (*Bulk rates as low as $0.55/lb) $20 Input of CO2 (LBS) per Use 1.75 Dry Ice Output (LBS) per Use 0.38 Lbs of Dry Ice made from 20 lbs CO2 4.34 Cost per lb of Dry Ice made (approx) $4.61 Brick Formation Time (approx) 25 Seconds Connection for CO2 (includes gasket not shown in photo*) CGA 320   Additionally, this dry ice maker comes with these extra items... 1 white plastic shim 1 Black upper gasket 1-Year BVV Warranty The Upgraded Valve Assembly option will include this manifold. Assembled in the USA by BVV  *Extreme cold temperatures will cause red paint to flake off of the jack over time. This is purely cosmetic.

Read more less

Cold Trap O-ring for Inner Vessel This is a replacement O-ring gasket for the inner vessel of the cold trap to create a seal between the lid and dry ice container. Material: Silicone

Read more less

MAXTRAP105 -105°C Vacuum Cold Trap, 120V       Cascade’s MAXTRAP105 is not an ordinary lab-grade cold trap. Cascade has integrated  features necessary for time-sensitive, high-throughput, production-focused vacuum purging or drying applications.   MAXTRAP105 Cold Trap Includes:   Cascade’s COLDWELL 304 Stainless Steel Trap Insert (Patent pending baffle system)   3 Quart Capacity (2839 ml)   Viton Gasket for Vacuum Integrity   Labconco -105°C Refrigerated Base   Green CFC / HFC Free Refrigerants   Power Cord   3mm Neoprene Insulator Cap   Requires 800ml (~ 3.5 cups) of a transfer fluid such as ethanol. Not Included. Cascade recommends: ethanol, glycol, cryo-cool fluids   Quality Made in USA   1 Year Warranty   Connection Lines and hardware: 4′ of 1″ Diameter Vacuum Tubing with KF-25 Flanges on each side. KF-25 clamps, centering rings for the connection tube     MAXTRAP Tips: Safety   At very cold temperatures, solvents and even oxygen can re-condense back into liquid. This is potentially explosive. Liquid oxygen is a light blue color and can condense into a cold trap if a pump has sucked air through the trap when the trap is very cold. Always follow your standard operating procedures and safety guidelines.   Don’t Stop: Keep Processing while trap is being reclaimed, cleaned, refreshed   Cold traps can become full or the captured material freezes and blocks flow. For high moisture, outgassing, 24 hour processing/vacuum purging consider adding a second, spare COLDWELL trap. The secondary COLDWELL can be dropped into place so processing continues while the full trap is cleaned, defrosted.   Quick Start Up Tips: Remove shipping foam from reservoir bottom prior to use   Fill reservoir with 800ml (+/-3.5 cups) ethanol to marked line   Monitor ethanol levels inside reservoir   Allow at least 30 mins for trap to cool   Keep side vents clear. Allow at least 4″ for airflow   Monitor interior of stainless trap for clogging   Short tube – attach to vacuum pump   Tall tube – attach to vacuum oven   MAXTRAP105 Differences:   The key to quality cold trap performance is: time, surface area, and temperature. Time: Most cold traps have very narrow inlets and outlets, slowing down your process. Not Cascade’s MAXTRAP105! Full KF25 inlet and outlet connections never reduce flow. Surface Area: Most cold traps have glass or a smaller surface area to collect the matter your vacuum pump would otherwise ingest. Cascade’s MAXTRAP105 surface area is a patent pending series of filter baffles inside the COLDWELL stainless trap.   Specifications Coldwell Stainless Trap KF25 Inlet & Outlet 3 Quart Capacity (2839 mliters) Viton Gasket Neoprene Insulator Cap Labconco -105°C Mechanical Base 115V / 1ph / 3 AMP (60Hz) Cord Included CFC / HCFC Free Refrigerants Dimensions inches 24.1 W x 23.9 D x 12.6 H cm 34.3 x 59.7 x 30.5 *Requires approximately 800ml (~ 3.5 cups) of transfer fluid(ethanol, glycol, cryo-cool fluids) Connections 1 each 4′ KF-25 flanged vacuum rated line 1 each KF-25 Centering Ring 1 each KF-25 Clamp Weight COLDWELL Stainless Trap: 14 lbs Mechanical Base: 139 lbs Shipping Weight: 190 lbs     Additional Resources: Download Specs  Download Supplemental Manual  NTRL Certifications  -105C Refrigerated Base  Safety Certification

Read more less

 Huber TC100   (Please Note: There is up to 2 -3 weeks Shipping lead time) The TC range of immersion coolers are a flexible solution for a variety of cooling tasks. The devices are simple and universally used for rapid cooling of fluids. Typical applications include counter-cooling for heat circulation thermostats or replacement of dry ice. For many applications immersion coolers are also an environmentally friendly alternative to mains water cooling. The TC immersion coolers are suitable for unsupervised use, for cooling tasks which require continuous cooling or as a variant with temperature control and a Pt100 probe. The models with the type affix "E“ have an LED display with entry of nominal values and regulate with a precision of ±0.5 K. A spiral-shaped or flexible immersion cooling probe made out of stainless steel is available for all models so that fluids can be cooled in virtually all vessel types. The compact housing is made from high quality stainless steel, and is fitted with carrying grips.     FEATURES: Universal solution for many cooling tasks Rapid cooling of fluids Ideal for counter-cooling or as a replacement of dry ice  LED temperature display Easy operation with only three keys   Compact, space-saving construction Robust housing with carrying grips   High quality stainless steel immersion probe   General information & temperature controller Model Sku / Power Supply 3005.0129.00 208V 2~ 60Hz 3005.0131.00 110-120V 1~ 50/60Hz Temperature range -100...40 °C -100...40 °C Controller ON-OFF-Regler ON-OFF-Regler Safety class I / NFL I / NFL Dimensions (W x D x H) 295 x 500 x 570 mm | 11.61 x 19.69 x 22.44 inches 11.61 x 19.69 x 22.44 inches Weight 61 kg | 134.5 pounds 134.5 pounds Heating / cooling capacity Cooling capacity 0 -20 -50 -60 -80 -90 -100 0,16 0,15 0,13 0,12 0,12 0,07 0,01 kW 0 -20 -50 -60 -80 -90 -100 0,16 0,15 0,13 0,12 0,12 0,07 0,01 kW Cooling machine air-cooled air-cooled Refrigerant 1. stage (ASHRAE, GHS) R452A (A1, H280) (0,26 kg) R452A (A1, H280) (0,26 kg) Refrigerant 2. stage (ASHRAE, GHS) R1150 (A3, H220) (0,056 kg) R1150 (A3, H220) (0,056 kg) Operating data Permissible ambient temp. 5...40 °C 5...40 °C Power supply 208V 2~ 60Hz 110-120V 1~ 50/60Hz Current max. 6,5 A -       Miscellaneous  Please take further technical information as well as information about the scope of delivery, accessories and peripheral devices from the PDF data sheet. In cases of doubt the details given in there apply. If nothing to the contrary is quoted then the performance data referred is at an ambient temperature of 20°C. Please observe the notes on installation and/or the space requirements of our products. The following voltage and frequency tolerances apply based on EN60034-1:Voltage +/- 5% for a frequency tolerance at the same time of +/- 2%. Examples to illustrate this: Not permissible, for example. is -5% on the voltage and +2% on the frequency. Permissible, on the other hand, are tolerances of -5% on the voltage and -2% on the frequency.This equipment is compliant to US-SNAP and all applicable EU laws. The US-SNAP end-use for this equipment is the industrial process refrigeration. Certification by a Notified Body upon request.We reserve the right to make technical changes and correct errors. Illustrations can deviate from the original.   Click here to see Warranty  Data sheet 3005.0129.00 Data Sheet 3005.0131.00

Read more less

Huber TC100E   The TC range of immersion coolers are a flexible solution for a variaty of cooling tasks. The devices are simple and universally used for rapid cooling of fluids. Typical applications include counter-cooling for heat circulation thermostats or replacement of dry ice. For many applications immersion coolers are also an environmentally friendly alternative to mains water cooling. The TC immersion coolers are suitable for unsupervised use, for cooling tasks which require continuous cooling or as a variant with temperature control and a Pt100 probe. The models with the type affix "E“ have an LED display with entry of nominal values and regulate with a precision of ±0.5 K. A spiral-shaped or flexible immersion cooling probe made out of stainless steel is available for all models so that fluids can be cooled in virtually all vessel types. The compact housing is made from high quality stainless steel, and is fitted with carrying grips.     Universal solution for many cooling tasks Rapid cooling of fluids Ideal for counter-cooling or as a replacement of dry ice LED temperature display  Easy operation with only three keys Compact, space-saving construction Robust housing with carrying grips High quality stainless steel immersion probe Temperature controller, stability ±0.5 °C External Pt100 sensor included (# 6138)       General information & temperature controller Temperature range -100...40 °C Temperature stability ±0.5 °C Alarm message optical, acoustical Controller MPC Safety class I / NFL Dimensions (W x D x H) 295 x 500 x 570 mm | 11.61 x 19.69 x 22.44 inches Weight 61 kg  |  134.5 pounds Heating / cooling capacity Cooling capacity 0 -20 -50 -60 -80 -90 -100 °C0,16 0,15 0,13 0,12 0,12 0,07 0,01 kW Cooling machine air-cooled Refrigerant 1. stage (ASHRAE, GHS) R452A (A1, H280) (0,26 kg) Refrigerant 2. stage (ASHRAE, GHS) R1150 (A3, H220) (0,056 kg) Connections Pt100 connection Pt100 Operating data Permissible ambient temp. 5...40 °C Noise level 55 dB(A) Power supply 110-120V 1~ 50/60Hz  208V 2~ 60Hz

Read more less

Polyscience IP-60 Low Temperature Cooler, 1.5" Rigid Coil Probe ***Note: This item has a possible lead time of 2-3 weeks depending on stock availability.***   Specification Description Immerson Probe-60, 1.5" Rigid Coil Working Temperature Range °C -60° to -20° Temperature Control (°C) Fixed at -60° Working Temperature Range °F -76° to -4° Working Temperature Range °C -60° to -20° Temperature Control (°F) Fixed at -76° Temperature Control (°C) Fixed at -60° Maximum Ambient Temperature °F 86° Maximum Ambient Temperature °C 30° Overall Dimensions (L x W x H) (inches) 11 x 10 x 9 in Overall Dimensions (L x W x H) (cm) 27.9 x 25.4 x 22.9 cm Refrigerant R404A & R508B Immersion Probe Type Rigid Coil Probe Diameter (inches) 1.5 Probe Diameter (cm) 3.81 Probe Length (inches) Coil: 4 / Exposed: 15 Probe Length (cm) Coil: 10.2 / Exposed: 38.1 Flexible Hose Diameter (inches) 1.5 Flexible Hose Diameter (cm) 3.81 Flexible Hose Length (feet) 4 Flexible Hose Length (m) 1.22 Shipping Weight (pounds) 49.0 Shipping Weight (kilograms) 22.0 Catalog Page Number 114-115 60 Hz Only Part Number P60N2A101B Cooling Capacity @ -60°C (W) 0 Cooling Capacity @ -40°C (W) 100 Cooling Capacity @ -30°C (W) 125 Cooling Capacity @ -20°C (W) 150 Electrical Requirements (VAC/Hz/Ph/A) 120/60/1/5     Key Features: Continuous cooling to temperatures as low as -60C Designed to run at maximum cooling An economic alternative to dry ice or liquid nitrogen Excellent for trapping applications, freeze drying, and rapidly cooling small volumes of liquids Operator's Manual

Read more less

 MAXTRAP50: -50°C Vacuum Cold Trap   There are numerous laboratory grade cold traps on the market and everyone agrees they are a best practice tool for preserving/extending vacuum pump life or the time between vacuum pump maintenance. Cascade’s MAXTRAP50 is not an ordinary lab-grade cold trap. Cascade has taken our extensive knowledge of vacuum best practices and integrated the features necessary for our customers with time-sensitive, high-throughput, production-focused vacuum purging or drying applications.   Complete System Includes:   Cascade’s COLDWELL 304 Stainless Steel Trap – patent pending baffle system.   3 Quart Capacity (2839 mliters)   Viton Gasket   Labconco -50°C Refrigerated Base   Green CFC / HFC Free Refrigerants   KF-25 Inlet/Outlet, 1 each 4′ Connection Line with KF-25 flanges, clamps, centering ring   Power Cord   3mm Neoprene Insulator Cap   Requires 800ml (~ 3.5 cups) of a transfer fluid such as ethanol. Not Included. Cascade recommends: ethanol, glycol, cryo-cool fluids   Quality Made in USA   1 Year Warranty   MAXTRAP Tips:   Safety At very cold temperatures, solvents and even oxygen can re-condense back into liquid. This is potentially explosive. Liquid oxygen is a light blue color and can condense into a cold trap if a pump has sucked air through the trap when the trap is very cold. Always follow your standard operating procedures and safety guidelines.   Don’t Stop: Keep Processing while trap is being reclaimed, cleaned, refreshed Cold traps can become full or the captured material freezes and blocks flow. For high moisture, outgassing, 24 hour processing/vacuum purging consider adding a second, spare COLDWELL trap.   The secondary COLDWELL can be dropped into place so processing continues while the full trap is cleaned, defrosted.      Quick Start Up Tips: Remove shipping foam from reservoir bottom prior to use   Fill reservoir with 800ml (+/-3.5 cups) ethanol to marked line   Monitor ethanol levels inside reservoir   Allow at least 30 mins for trap to cool   Keep side vents clear. Allow at least 4″ for airflow   Monitor interior of stainless trap for clogging   Short tube – attach to vacuum pump   Tall tube – attach to vacuum oven   MAXTRAP50 Differences:   The key to quality cold trap performance is: time, surface area, and temperature.   Time:  Most cold traps have very narrow inlets and outlets, slowing down your process. Not Cascade’s MAXTRAP50! Full KF25 inlet and outlet connections never reduce flow.   Surface Area:  Most cold traps have glass or a smaller surface area to collect the matter your vacuum pump would otherwise ingest. Cascade’s MAXTRAP50 surface area is a patent pending series of filter baffles inside the COLDWELL stainless trap.   Temperature:  Cascade’s MAXTRAP50 features the mechanically refrigerated system built in the USA by Thermo Scientific – a leader in laboratory equipment.     Specifications Coldwell Stainless Trap KF25 Inlet & Outlet 3 Quart Capacity (2839 mliters) Viton Gasket Neoprene Insulator Cap Labconco -50°C Mechanical Base 115V / 1ph / 3 AMP (60Hz) Cord Included CFC / HCFC Free Refrigerants Dimensions inches 13.5 W x 23.5 D x 12.0 H cm 34.3 x 59.7 x 30.5 *Requires approximately 800ml (~ 3.5 cups) of transfer fluid(ethanol, glycol, cryo-cool fluids) Connections 1 each 4′ KF-25 flanged vacuum rated line 1 each KF-25 Centering Ring 1 each KF-25 Clamp Weight COLDWELL Stainless Trap: 14 lbs Thermo Mechanical Base: 60 lbs Shipping Weight: 95 lbs     Additional Resources: Download Specs  Download Supplemental Manual  NRTL Certifications

Read more less

Polyscience IP-100 Low Temperature Cooler, 3" Rigid Coil Probe ***Note: This item has a lead time of 2-3 weeks depending on stock availability.***   Key Specifications Description Immersion Probe-100, 3" Rigid Coil Display Temperature Working Temperature Range °C -100° to -60° Working Temperature Range °F -148° to -76° Working Temperature Range °C -100° to -60° Temperature Control (°F) Fixed at -148° Temperature Control (°C) Fixed at -100°C Cleanable Air Filter Yes Display Temperature Maximum Ambient Temperature °F 86° Maximum Ambient Temperature °C 30° Overall Dimensions (L x W x H) (in) 20.1 x 15 x 22.3 in Overall Dimensions (L x W x H) (cm) 51.1 x 38.1 x 56.6 cm Refrigerant R404A & R508B Immersion Probe Type Rigid Coil Probe Diameter (inches) 3 Probe Diameter (cm) 7.62 Probe Length (inches) Coil: 9 / Exposed: 17 Probe Length (cm) Coil: 22.9 / Exposed: 43.2 Flexible Hose Diameter (inches) 2.83 Flexible Hose Diameter (cm) 7.14 Flexible Hose Length (feet) 6 Flexible Hose Length (m) 1.83 Shipping Weight (pounds) 162.0 Shipping Weight (kilograms) 73.5 Catalog Page Number 114-115 60 Hz Only Part Number P10N6A101B Cooling Capacity @ -100°C (W) 0 Cooling Capacity @ -80°C (W) 35 Cooling Capacity @ -65°C (W) 85 Electrical Requirements (VAC/Hz/Ph/A) 120/60/1/11.5      Key Features: Continuous cooling to temperatures as low as -100C Designed to run at maximum cooling An economical alternative to dry ice or liquid nitrogen Excellent for trapping applications, freeze drying, and rapidly cooling small volumes of liquids  Operator's Manual

Read more less

This tank regulator will control the rate of fluid or gas flow using a butterfly valve.  Our BVV butterfly valve is rated to 1000 psi, and is made of 304 stainless steel and features a PTFE valve seat making it compatible with CO2.  The output will connect to a 1/2" JIC flare hose (seen here BVV JIC 1/4" Hose).
