The guaranteed industry standards ability to lose less than 1” Hg over a 24-hour period.
Reliable deep vacuum that reaches below 0.1 torr. with stainless steel compression-fit tubing and stainless steel instrumentation valves.
Uniform heat which is key to an effective oven. Our ovens offer 7% temperature uniformity across all shelves with offering ±1⁰ stability in temperature.
Comes standard with the maximum number of shelves and a well-lit LED interior.
Items Included: 5' 37⁰ female flared HVAC hose; USA power cord; and oven operation manual. You’ll get the complete package only with BVV.
2 year limited warranty
Key Oven Features:
1/4" JIC Vacuum Port with included 5' HVAC Hose
Easy Vac-Release Dial allows release of vacuum without disconnecting pump or purge
Stainless steel interior for a sanitary, easy-to-clean look
Overload circuit breaker for electrical protection
Comes standard with 4 (0.9CF Eco models) or 5 shelves (1.9CF Eco models)
Specifications
Electrical
120 VAC / 60Hz / 700W / USA Plug
Internal Chamber
Four Wall Heating
Material: Polished Stainless Steel
Dimensions (LxWxH): 11-1/2" x 11-3/4" x 10-3/4"
Temperature Control
LED PID Controller
Temperature Range: Room Temperature - 212⁰F
Temperature Stability: ± 1.8⁰F or ± 1⁰C
Automatic Over Shoot Shut Down
Over Temp Alarm
Vacuum Gauge
Ranging from -1inHG to -30inHG
Maximum Vacuum Level
-29.9” Hg / -75.4 cmHg / -1 MPa /
Shelves
Up to 8 sliding shelves at one time
Reinforced steel with sides to secure product
Shelf Capacity (area): 129 in2
Total Shelf Capacity: 1035 in2 or 7.2 ft2
Dimensions (LxW): 11-3/8" x 11-3/16"
Door
½” Tempered Glass window with LEDs
Window Dimensions (LxH): 11-3/4" x 11"
Replaceable Gasket material: Silicone
Weight & Dimensions
Outside Dimensions (LxWxH): 24.5”w x 22”d x 21”h
Weight: 115lbs
Compliant
CE Listing Recognized
ISO 9001: 2008
ISO 13485: 2003
Manufactured in Acc. w/ Q/TIWY7-2004
IEC68-2-3
Note: This oven does NOT contain a vacuum pump. External pump is required to achieve vacuum pressure.
