MFR: SSP CorporationSKU: ISST4ST
30 Day Limited Warranty
Made in the USA
You will earn 0 points for this purchase.
SSP Instrumentation TruFit® is manufactured from fully-traceable raw material to close tolerances and superior surface finishes. TruFit® provides optimal performance when installed in accordance with SSP’s recommendations and the design parameters appropriate for each type of connection – tapered thread, straight thread, and weld & braze. TruFit® components are cleaned in accordance with SSP documented work instructions using equipment calibrated to NIST standards with environmentally-safe and stable agents, ultrasonics, and heat/ temperature to remove all residual oil, grease, and loose particles. Stainless steel components are passivated to the requirements of MIL QQ-P-35 and ASTM A 967.
***Note: ALL NPT Threads REQUIRE the user to properly install the fitting by using a thread sealant to prevent leaks. Best Value Vacs recommends GAS PTFE Tape
|Connection Type 1||Female NPT|
|Connection Size 1||Specified by User|
|Connection Type 2||Female NPT|
|Connection Size 2||Specified by User|
|Connection Type 3||Male NPT|
|Connection Size 3||Specified by User|
|Material||316 Stainless Steel|
|ASTM A-276 and A-479 bar stock, A-182 forgings.|
|Working Pressure (PSIG)||1/4" - 7750|
|3/8" - 6800|
|NPT Pressure Rating||>10,000PSI|
SSP proudly makes Duolok®, TruFit®, FloLok® and hundreds of other products 100% in the USA!
