| PPF Efficacy: |
2.56 at 120VAC |
| Photon Flux (µmol/s) (400-700nm): |
870 |
| Photon Flux Blue (µmol/s) (400-500nm): |
161
|
| Photon Flux Green (µmol/s) (500-600nm): |
355
|
| Photon Flux Red (µmol/s) (600-700nm): |
355
|
| Total Blue/Red - Energy Bands: |
516
|
| % Blue: |
18.51% |
| % Green: |
40.76% |
| % Red: |
40.73% |
| POWER |
| Power Consumption: |
340W AC |
| Driver: |
Sosen |
| Power Factor: |
>0.95 |
| Surge Protection: |
6 KV |
| 120V: |
2.90 A |
| 208V: |
1.75 A |
| 240V: |
1.51 A |
| 277V: |
1.31 A |
| DIMENSIONS |
| Fixture Size (driver mounted on the fixture): |
(L) 43.7” x (W) 22” x (H) 4.1” |
| Fixture Size (without driver): |
(L) 43.7” x (W) 22” x (H) 1.6” |
| Power Supply Dimension: |
(L)18.7” X (W) 4.4” X (H) 2.4” |
| Driver Net Weight: |
6 lb. |
| Fixture Net Weight: |
6 lb. |
| OTHER |
| Mounting Height |
>6” above canopy |
| Beam Angle |
120 Degree |
| Input Voltage |
100 - 277 VAC |
| Manual Dimming Knob |
Yes |
| Built In Control Ports |
Yes |
| Standard Power Cord (Extensions available) |
AWG 18, 6 Foot |
| Standard Plug |
120 VAC - NEMA 5-15P |
| Substitute Plugs (Upon request at order for bulk purchases) |
240 VAC, 277 VAC, Pigtails |
| Adjustable Height Hanging Kit Included |
Yes |
| Fixture Warranty |
7 Years Limited |
| Driver Warranty |
8 Years Limited |
| ETL Safety Certified |
Conforms to UL 1598:2018 Ed.4
Certified to CSA C22.2#250.0:2018 Ed.4
*ETL Safety Certified No. 5020070 |
