Specs-At-A-Glance |
Temperature Stability (°C) |
±0.05 … ±0.1 |
Cooling Capacity |
°C 200 20 0 -20 -40 -60 -80 kW 2.8 2.5 2.4 2.4 2.4 2.2 0.4
|
Heating Capacity (kW) |
6 @ 400V, 6 @ 230V, 5.5 @ 208V |
Heating or Cooling Capability |
Both |
Working Temp Range (°C) |
-85 … +250 |
Pump Capacity Flow Rate (l/min) |
35 … 76 |
Pump Capacity Flow Pressure (psi) |
6.96 … 46.42 @ 400V, 6.96 … 46.42 @ 230V, 6.96 … 43.51 @ 208V |
Filling Volume Liters |
9.5 (7 internal expansion) |
Digital Interface |
RS232, Optional Profibus, SD memory card, USB, Ethernet, Modbus, Optional RS485 |
Noise Level (dBA) |
69 |
Power requirement V / Hz / A |
3x 208/60/30 |
Cooling of Compressor |
2-stage Air |
External Devices |
External Temp Probe, Remote Control |
Dimensions W x L x H (in) |
24.1 x 42.6 x 49.3 |
Fluid Type |
Silicone, Fluorinert/Galden, Other |
Weight (lbs) |
805 |
