Specifications |
Shipping Weight |
185 lbs |
Shipping Dimensions |
32 x 24 x 40 in |
Order No. |
9420300 |
Model Series |
PRESTO |
Working Temperature Range (°C) |
-30° … +250° |
Temperature Stability (°C) |
±0.01 … ±0.05 |
Temperature Control |
ICC intelligent cascade control, TCF temperature control features, Absolute temperature calibration 1-point |
Display Resolution |
0.01 °C |
Integrated Programmer |
8×60 steps |
Temperature Display |
TFT Touchscreen |
Heating Capacity (kW) |
2.3 |
Cooling Capacity |
°C 200 100 20 0 -10 -20 -30
kW 0.5 0.5 0.5 0.4 0.3 0.2 0.05
|
Pump capacity Flow Rate (l/min) |
25 |
Pump Capacity Flow Pressure (psi) |
7.25 |
Pump Connections |
M24x1.5 |
Filling Volume Liters |
2.4 (1.5 internal expansion) |
Refrigerant |
R507 |
External Pt100 |
integrated |
Digital Interface |
RS232, Optional Profibus, SD memory card, USB, Ethernet, Modbus, Optional RS485 |
Ambient Temperature |
5…40 °C |
Noise Level (dBA) |
54 |
Classification |
Classification III (FL)according to DIN 12876-1 |
Analog Connection Input / Output |
Optional |
Cooling of Compressor |
1-stage Air |
Filling Volume Expansion Vessel Liters |
1.5 |
Power requirement V / Hz / A |
208/60/14 |
Heaters |
2.1kW @ 200V (2.7kW @ 230V) |
Alarm Signal |
acoustically & optical |
Temperature Selection / Display |
°C / °F |
Outer dimensions W x L x H inch |
9.5×9.5×24 |
Available Voltage Versions |
- 230V/50Hz
- 208V/60Hz
- 208V/60Hz (Canadian and US NRTL Certified)
|
Other Characteristics |
GB version with 2100 W heater capacity / CH version with 1700 W heater capacity |
Characteristics / Display |
State-of-the-art display technology: TFT Display for comfortable user guidance, colored display of measurement values, graphs and control options, user-defined views |
Characteristics / Operation |
Convenience for several users: Administrator level for customizing instrument settings, user levels with limited permissions for fast and safe defined access, password protection, all levels adjusta, Instructions inside: Help menus and explanations in plain text for all control options, help messages and warning messages, Multilingual user guidance: Language selection for display of control options, notifications and warning messages via touchscreen, Optimal ease of use: Touch screen for direct operation via display |
Characteristics / Temperature Control |
For perfect results: Intelligent Cascade Control, automatic & self optimizing adjustment of PID control parameters, temperature stability ±0.01 °C … |
Characteristics / Refrigeration Technology |
100 % Cooling capacity: Active Cooling Control for cooling available throughout the entire working temperature range, fast cool-down even at higher temperatures, Consistent cooling capacity: Easily removable venting grid for quick and easy cleaning, Energy saving cooling: Proportional cooling control for automatic adjustment of cooling power or temporary switch-off of compressor as needed to save up to 90 % energy in comparison to unregulated c |
