Order No. |
9666200 |
Model Series |
FL Series |
Working Temperature Range (°C) |
-25° to +40° |
Temperature Stability (°C) |
±0.05 |
Temperature Control |
PID temperature control |
Display Resolution |
0.01 °C |
Temperature Display |
LED |
Cooling Capacity |
10 kW @ 0 °C, 2.5 kW @ 20 °C, 20 kW @ 20 °C, 6 kW @ -10 °C |
Pump capacity Flow Rate (l/min) |
80 |
Pump Capacity Flow Pressure (psi) |
11.6...87.0 |
Pump Connections |
G1 1/4-inch |
Filling Volume Liters |
15 to 37 |
Barbed fittings diameter (inner dia. / mm) |
1-inch |
Pressure Indicator (psi) |
0...87 |
Filling Volume Liters |
15...37 |
Refrigerant |
R404A |
Digital Interface |
RS232, Optional Profibus |
Ambient Temperature |
5…40 °C |
Noise Level (dBA) |
73 |
Classification |
Classification III (FL)according to DIN 12876-1 |
Included with |
2 barbed fittings for tubing 3/4" inner dia. (pump connections G3/4"male) |
Cooling of Compressor |
Air |
Power requirement V / Hz / A |
3x 230/60/36 |
Cooling capacity °C |
20kW (@ 20°C), 15kW (@ 10°C), 10kW (@ 0°C), 6kW (@ -10°C), 2.5kW (@ -20°C) |
Alarm Signal |
acoustically & optical |
Temperature Selection / Display |
°C |
Volumetric Capacity Liters |
15...37 |
Outer dimensions W x L x H inch |
37.4 x 45.3 x 63.4 |
Available Voltage Versions |
230 V / 50 Hz, 230 V / 60 Hz |
Other Characteristics |
Removable venting grid for convenient cleaning to maintain cooling performance. Internal pump by-pass valve to regulate pressure. |
Characteristics / Display |
Easy to read: Large LED temperature display for actual value and setpoint(resolution 0.1 °C) |
Characteristics / Operation |
Simple and fast : Convenient 3-key setpoint adjustment (FLmodels) |
Characteristics / Temperature Control |
Precise: PID Temperature control with set control parameters, temperature stability ±0.02…±0.2 °C |
Characteristics / Refrigeration Technology |
Consistent cooling capacity: Easily removable venting gridfor quick and easy cleaning |
Characteristics / Technical Features |
Serial connection: RS232 interface for PC connection, e.g. data communication and recording of measured values |
