Order No. |
9663012 |
Model Series |
FL Series |
Working Temperature Range (°C) |
-20° to +40° |
Temperature Stability (°C) |
±0.05 |
Display Resolution |
0.01 °C |
Temperature Display |
LED |
Cooling Capacity |
°C 20 0 -10 -20 kW 1.2 0.8 0.5 0.2
|
Pump capacity Flow Rate (l/min) |
40 |
Pump Capacity Flow Pressure (psi) |
7.25...43.51 |
Pump Connections |
G3/4" |
Barbed fittings diameter (inner dia. / mm) |
3/4" |
Filling Volume Liters |
12 ...17 |
Refrigerant stage 1 |
R452A |
Filling volume refrigerant stage 1 (g) |
690 |
Global Warming Potential for |
2140 |
Carbon dioxide equivalent stage 1 (t) |
1.477 |
Digital Interface |
RS232, Optional Profibus |
Ambient Temperature |
5…40 °C |
Dimensions W x L x H (inch) |
19.7 x 29.9 x 25.2 |
Weight (LBS) |
161 |
Noise Level (dBA) |
61 |
Description |
Suitable fluids: water, water-glycol mixture, JULABO Thermal bath fluids |
Included with |
2 barbed fittings for tubing 3/4" inner dia. (pump connections G3/4" male) |
Cooling of Compressor |
Air |
Power requirement V / Hz / A |
230/60/11 Additional voltage versions available |
Available Voltage Versions |
-230 V / 50 Hz
-230 V / 60 Hz |
Characteristics / Display |
Easy to read: Large LED temperature display for actual value and setpoint(resolution 0.1 °C) |
