Technical Data |
Order No. |
9013707 |
Model series |
CORIO |
Category |
Refrigerated - Heating Circulators |
Working temperature range (°C) |
-50 ... +200 |
Temperature control |
PID |
Temperature stability (°C) |
±0.03 |
Setting / display resolution |
0.01 – 0.1 °C |
Temperature Display |
LED |
Heating capacity (kW) |
1 |
Cooling capacity (Medium Ethanol) |
°C 20 10 0 -10 -20 -30 -40 kW 1 1 0.9 0. 73 0.5 0.3 0.13 |
Pump capacity flow rate (l/min) |
8 ... 27 |
Pump capacity flow pressure (psi) |
1.5 ... 10.2 |
Bath opening / bath depth (W x L / D inch) |
7.1 x 5.1 / 5.9 |
Pump connections |
M16x1 |
Barbed fittings diameter (inner dia. / mm) |
8 / 12 |
Filling volume (liters) |
5 ... 7.5 |
Refrigerant stage 1 |
R449a |
Filling volume refrigerant stage 1 (g) |
175 |
Ambient temperature |
5...40 °C |
Dimensions W x L x H (inch) |
16.5 x 19.3 x 27.6 |
Weight (LBS) |
113.5 |
Included with each unit |
2 Schlaucholiven passend für Schlauch 8 und 12 mm l.W. (Pump enanschlüsse mit M16x1 Außengewinde) |
Bath tank |
Stainless steel |
Bath cover |
integrated |
Cooling of compressor |
Air |
