Specifications |
Order No. |
9012701 |
Model series |
CORIO |
Category |
Refrigerated - Heating Circulators |
Working temperature range (°C) |
-20 ... +150 |
Temperature control |
PID |
Temperature stability (°C) |
±0.03 |
Setting / display resolution |
0.01 – 0.1 °C |
Temperature Display |
LED |
Heating capacity (kW) |
1 |
Cooling capacity (Medium Ethanol) |
°C 20 0 -20
kW 0.22 0.17 0.06
|
Pump capacity flow rate (l/min) |
15 |
Pump capacity flow pressure (psi) |
5.08 |
Bath opening / bath depth (W x L / D inch) |
5.1 x 5.9 / 5.9 |
Pump connections |
M16x1 |
Barbed fittings diameter (inner dia. / mm) |
8 / 12 |
Filling volume (liters) |
3 ... 4 |
Refrigerant stage 1 |
R134a |
Filling volume refrigerant stage 1 (g) |
70 |
Global Warming Potential for |
1430 |
Carbon dioxide equivalent stage 1 (t) |
0.1 |
Ambient temperature |
5...40 °C |
Dimensions W x L x H (inch) |
9.1 x 15.4 x 25,6 |
Weight (LBS) |
57.4 |
Included with each unit |
2 each barbed fitting for tubing 8 and 12 mm inner dia. (pump connections M16x1 male) |
Bath tank |
Stainless steel |
Bath cover |
integrated |
Cooling of compressor |
Air |
