Insulated Heavy Duty 1/8" Wall Silicone Tubing For Flow - 6 Feet
(**Note: This tubing is only for flow and is NOT vacuum rated)
The most outstanding properties of SILCON tubing are its flexibility and resistance to temperature extremes. These, plus its good electrical properties and ability to self-extinguish, make SILCON tubing an excellent choice for appliances and computers
Peroxide-cured SILCON contains no sulfur or other acid-producing chemicals, thereby eliminating the possibility of staining, corroding, or deteriorating materials it contacts. It is extremely resistant to ozone and U.V. over long time periods.
Care is recommended in the selection of fittings and clamps for SILCON as sharply barbed fittings or unlined metal clamps could tear into the tubing wall and possibly cause a failure.
SILCON may be low-pressure steam sterilized in-line or autoclaved at up to 250°F in a normal autoclaving cycle. However, if exposed to repeated steam sterilization or long-term high temperature or pressure, silicone will eventually relax and become gummy. It should then be replaced.
Insulation Compliance:
ASTM C 534, Type I – Grade 1
ASTM D 1056, 2C1
ASTM E 84, UL723
ASTM G21/C1338
CAN/ULC S102 ➀
City of New York Approval MEA 107-89M
MIL-P-15280J, FORM T ➁
NFPA 90A, 90B
UL 181
UL 94 5V-A, V-0, File E55798
Insulation Approvals, Certifications, Compliances:
3rd party certified by FM Approvals through 1-1/2" wall thickness per FM 4924
GREENGUARD® Children & Schools Indoor Air Quality certified.
Manufactured without CFCs, HFCs, HCFCs, PBDEs, or Formaldehyde.
Made with EPA registered Microban® antimicrobial product protection.
All Armacell facilities in North America are ISO 9001:2008 certified.
Plenum Rated
Conforms to ASHRAE 90.1 Energy Standards
Conforms to building codes: International Mechanical Code, IMC, International
Energy Conservation Code, IECC, International Residential Code, IRC, Title 24California Building Energy Efficiency Standards.
Please call or email Best Value Vacs to request different sizes and thickness (1/16" to 3/4"ID) - Colors for industrial applications are available through minimum order.
Key Features:
Made from FDA-sanctioned ingredients
Insulation R-Value of 3.3
Able to resist extreme temperature variation: -100°F to 500°F
Translucent natural color for visual contact with the flow
resilient, stretchable, and resistance to compression set
Odorless, tasteless and inert
Good electrical and weatherability properties - resists U.V., ozone, gases, and moisture
Certified by the National Sanitation Foundation (NSF-51) for food equipment materials
MADE IN THE U.S.A.
Specifications/Physical Properties
Hardness, Shor A +/-5
50
Tensile Strength, PSI
1100
Elongation at Break %
375
Brittle Temperature °F
-100
Max Operating Temperature °F
500
Max Operating Temperature for NSF °F
350
Comp. Set 22 Hrs. at 177°F, %
35
Tear Resistance (PPI minimum)
100
Tubing Specifications Chart
ID (IN.)
OD (IN.)
STANDARD LENGTH
WORKING PSI @ 70°F
BURST PSI @ 70°F
LBS PER 100FT
1/16
1/8
100
10
30
0.50
1/16
3/16
100
20
60
1.34
3/32
5/32
100
10
30
0.66
3/32
7/32
100
15
45
1.58
1/8
3/16
100
10
30
0.88
1/8
1/4
100
20
60
2.00
1/8
5/16
100
25
75
3.32
1/8
3/8
100
28
84
4.92
5/32
9/32
100
20
60
2.14
5/32
11/32
100
20
60
3.64
3/16
1/4
100
5
15
1.22
3/16
5/16
100
20
60
2.64
3/16
3/8
100
20
60
4.12
3/16
7/16
100
15
45
6.14
1/4
5/16
100
10
30
1.50
1/4
3/8
100
5
15
3.34
1/4
7/16
100
20
60
5.12
1/4
1/2
100
15
45
7.50
5/16
7/16
100
10
30
3.66
5/16
1/2
100
10
30
6.30
3/8
1/2
100
10
30
4.32
3/8
9/16
100
10
30
7.15
3/8
5/8
100
10
30
10.16
3/8
3/4
100
15
45
16.72
7/16
5/8
100
10
30
7.70
1/2
5/8
100
5
15
5.84
1/2
11/16
100
5
15
9.50
1/2
3/4
100
10
30
13.12
1/2
7/8
100
10
30
15.00
5/8
3/4
100
5
15
6.86
5/8
13/16
100
5
15
11.34
5/8
7/8
100
5
15
13.38
5/8
1
100
10
30
22.86
3/4
1
50
5
15
17.64
3/4
1-1/8
50
10
30
26.56
